Relying on the rich experience of R&D for materials and products and adapting technology innovation methods such as advanced engineering calculation software, 3D collaborative design based on PDM management, simulation analysis and system optimization, CRRC QSYRI has shorten the R&D cycle, improved design precision, and enhanced reliability and safety of products.

Advanced Engineering Calculation Software

Professional design software ‘Romax’ and self-developed ‘Specialized Calculation Procedure’ based on engineering calculation software “Mathcad” are used on the system design, so as to assure design efficiency and reliability.

01——Romax for systematic design

02——Mathcad for design calculation

3D collaborative design based on PDM management

3D design software ‘Pro/E’ is widely used for integrated modeling of product and PDM is adapted to manage full life circle of product.

03——3D collaborative design based on PDM management

System Optimization

With the design concept of full life circle for product, the company operates simulation verification for key performances like heating of system, noise of vibration, lubrication, sealing, fatigue life and so forth to gurantee safety and availiability of in-service product.

04——Optimization System

05——Flexibility Analysis

06——Flexibility Analysis
