| SDD4 diesel locomotive is a broad-gauge, AC-DC electric shunting locomotive, which is exported to Kazakhstan and Tajikistan, etc. The locomotive adopts single driver's cab and outside corridor structure, equipped with a 12V240ZJ diesel engine, with a service power of 2200KW and a maximum running speed of 100km/h. It is equipped with microcomputer control system and running safety speed monitoring system. |
|
Main Technical Parameters |
| Application | Shunting & transfer service | Track Gauge | 1520 mm |
| Axle Arrangement | C0-C0 | Wheel Diameter | 1050 mm |
| Axle Load | 23 t | Locomotive Service Weight | 138 t |
| Max. Service Output of Diesel Engine | 2000 kW | Min. Negotiable Curve Radius | 100 m |
| Max. Running Speed | 100 km/h | Continuous Speed | 16 km/h |
| Max. Starting Tractive Effort | 442 kN | Continuous Tractive Effort | 340 kN |
| Fuel Capacity | 6200 L | Oil Capacity | 1000 kg |
| Sand Capacity | 800 kg | Overall Dimensions (L×W×H) | 20050mm×3300mm×4750mm |
