参数                                                 GS70
自重/t                                               23
载重/t                                               70
轴重/t                                               23.25
自重系数                                         0.33
每延米重/t.m-1                                7.74
罐体总容积/ m3                              39.2
罐体有效容积/ m3                          38
车辆最大宽×高/mmXmm              2939X3969
车辆长度/mm                                  12016
换长                                                 1.1
车辆定距/mm                                   7500
通过最小曲线半径/mm                   145
商业运营速度/km.h-1                      120
车钩中心线距轨面高度(空车) /mm 880±10
全车制动倍率                                   7.5
全车制动率 空车                              27.2%
                     重车                              17.3%
装卸方式                                           上装上卸
限界                                                   符合GB146.1-83
