Track gauge | 1,520 mm |
Line voltage | 25kV/50Hz |
Transmission | AC/AC |
Wheel arrangement | 2(Bo-Bo) |
Axle load | 25.0 t |
Power rating | 6,000 kW |
Design speed | 120 km/h |
Starting effort | 760kN |
Min. curve negotiation radius | 125m |
Length over coupler centers | 2 x 19,075 mm |
Application | Freight on main line |
Customer | Uzbekistan |
