Transmission | AC/AC |
Wheel arrangement | Co-Co |
Axle load | 25±13% t |
Service power | 3,500 kW |
Design speed | 100 km/h |
Starting effort | 560 kN |
Min. curve negotiation radius | 100 m |
Length over coupler centers | 22,250 mm |
Diesel engine model | 12V265 |
Application | Shunting on marshalling |
