Gauge | 1,435 mm |
Transmission | AC-DC-AC |
Wheel arrangement | Co-Co |
Axle load | 25 t |
Service power | 3,530 kW |
Max. running speed | 100 km/h |
Starting effort | 560 kN |
Min. curve negotiation radius | 100 m |
Length over coupler centers | 21,800 mm |
Diesel engine model | R12V280ZJ |
Application | Shunting and district transfer |
